Features
- 5 memory sets of sparking parameters ( Optional 10 sets
- EDP Function : Point sparking ( Surface sparking )
- Display mode : DSP, Wear , Depth , End, Pn
- Automatic / Manual work piece surface sensing
- Automatic / Manual electrode compensation
- Metric / Inch conversion
Specifications
| Model no | River 3 |
| Table travel (X,Y axes) |
300 x 200 mm |
| Work table size | 350 x 250 mm |
| Z axis travel | 350 mm |
| W axis travel | 200 mm (300 Opt.) |
| Max. workpiece height | 180 mm (300 Opt.) |
| Max. workpiece weight | 150 kgs |
| Power input | According to local voltage |
| Max. average current | 25 Amps |
| Power capacity | 3.8 KVA |
| Electrode diameter | 0.2 ~ 3.0mm |
| Machine net weight | 600 kgs |
| Depth / Width / Height | 1100 x 1100 x 2000 mm |
*Due to continuous research and development, all specifications and design characteristics are subject to change without prior notice.
